FEATURES

Protection for Pump

• Over Current (Over Load) Protection
• Over Voltage Protection
• Under Voltage Protection
• Phase Reversal Protection
• Phase Loss Protection
• Phase Unbalance Protection
• Pump Dry Run Protection
• Pump Stalled / Short Circuit Protection.
• Earth Fault Protection.
• Pump Moisture Protection.
• Pump Over Heat Protection
• Low PF Protection

Graphical Display

• Graphical LCD Displaying Pump running state & water level indication of both tanks
• Display of all Three Phase Voltage & Three Phase Current continuously
• Display of Power Parameters – KVA / KVAH , KW / KWH , HZ / PF
• Pump Running Graphics
• Pressure Level Status – Pressure High / Low
• Display of last Twenty Faults
• Total Pump Accumulative Running Time Display
• Pump Last Run Time Display
• Selection of Auto / Manual Mode

Pump Operation

• Auto / Manual
• Time Based ON/OFF
• Real Time ON/OFF
• Multi Tank Level Operation.
• Water supply by pressure control through Pressure Tank and Pressure Switch
• Water Supply by Level control through Level probe or Float Switch
• RS485 RTU Modbus Communication for PC Interface to Monitor / Control from Remote Location

General

• User-Friendly wiring connection
• Integrated Design, Easy To Install
• Industrial Grade Design
• Dimensions : 275 x 170 x 100

Optional

• Level Card
• Modbus RTU
• CBCT Coil
• Level Probe
• Temperature & Moisture fault contact of motor

Areas of Applications

• Farm & Agriculture
• Multi- Storey Apartments
• Hotels & Restaurants
• Hospitals
• Commercial Buildings
• Industries
• Government Water Works
• Bunglows
